MIL-DTL-24705-1 Penetrators, Multiple Cable, Electric Cable, Rectangular Metal Frame, Square-Faced Blocks

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. . .
MIL-DTL-24705/1B(SH)
END-PACKING ASSEMBLY. End-packing assembly styles shall be as specified on figures 3, 4, and 5.
(2) 3/8-16 UNC-2B
HEX NUT
END-PACKING
PLATE
(1.19) 30.1
(1.19) 30.1
(4.33) 110.0 RADIUS
0.79 (20.1) DIA.
(2) 3/8-16 UNC-2A
HEX HEAD BOLT
PIN MARKING
IN THIS AREA
(3.25)
82.55
(1.58) 40.1
(4.72) 119.9
FIGURE 3. Style 1A end-packing assembly.
(2)3/8-16 UNC-2B
(1)END-PACKING
HEX NUT
PLATE
(1.19) 30.1
(1.19) 30.1
PACKING
(1)END-PACKING
MATERIAL
PLATE SPECIAL WITH
(0.79) 20.1 DIA
WELDED STUD
3/8-16 UNC-2A
110.0 RADIUS
(1.58) 40.1
PIN MARKING
IN THIS AREA
4.722 (119.9)
FIGURE 4. Style 1B end-packing assembly.
4
