MIL-DTL-24705/1B(SH)
TWO-PIECE SQUARE-FACED CABLE INSERT BLOCK. Two-piece square-faced cable insert blocks shall
B (DIAMETER)
(2.362)
60.0
C
COLOR DOTS (OPTIONAL)
C
A
FIGURE 10. Two-piece square-faced cable insert block.
NOTE: Alternate construction for two-piece square-faced insert block. For BN80 and larger, the two
individual blocks may be molded as one piece and slit on one side for convenience in assembly.
TABLE II. Two-piece square-faced cable insert block dimensions (exterior width 15 90 mm).
Designator
A
B
C
Color dots
4.02
5.0
7.5 (0.30)
Red
BN1503/05
15.0 (0.59)
(0.16)
(0.20)
BN1504
15.0 (0.59)
4.0 (0.15)
7.5 (0.30)
---
BN1505
15.0 (0.59)
5.0 (0.20)
7.5 (0.30)
---
7.0
BN1505/07
15.0 (0.59)
6.03
7.5 (0.30)
White
(0.28)
(0.24)
BN1506
15.0 (0.59)
6.0 (0.24)
7.5 (0.30)
---
BN1507
15.0 (0.59)
7.0 (0.28)
7.5 (0.30)
---
8.04
9.0
7.5 (0.30)
Blue
BN1507/09
15.0 (0.59)
(0.32)
(0.35)
BN1508
15.0 (0.59)
8.0 (0.32)
7.5 (0.30)
---
BN1509
15.0 (0.59)
9.0 (0.35)
7.5 (0.30)
---
4.02
6.0
10.0 (0.39)
Green
BN2003/06
20.0 (0.79)
(0.16)
(0.24)
BN2004
20.0 (0.79)
4.0 (0.15)
10.0 (0.39)
---
BN2005
20.0 (0.79)
5.0 (0.20)
10.0 (0.39)
---
BN2006
20.0 (0.79)
6.0 (0.24)
10.0 (0.39)
---
7.04
9.0
10.0 (0.39)
Pink
BN2006/09
20.0 (0.79)
(0.28)
(0.35)
BN2007
20.0 (0.79)
7.0 (0.28)
10.0 (0.39)
---
9
