MIL-DTL-24705/1B(SH)
(0.18)
(4.64)
4.6
117.9
(3.19)
(2.41)
81.0
61.2
(0.18) 4.6
(0.39)
(5.00)
9.9
127.0
(0.41)
10.4
(0.48) 12.2
PIN MARKING
IN THIS AREA
4.330 (110.0) RADIUS
NOTE: The compression plate shall be provided with a means to restrain movement of the compression plate since
compression takes place during assembly.
FIGURE 6. Compression plate for style 1A and 1B end-packing.
(5.000)
127.0
(4.666)
118.5
(3.170)
(2.264)
(2.480)
80.5
57.5
63.0
FRONT
(4.547)
115.5
PIN MARKING
IN THIS AREA
(0.650) 16.5
(0.492) 12.5
FIGURE 7. Compression plate for style 2A end-packing.
