MIL-DTL-24705B(SH)
TABLE III. Conformance inspection.
Inspection
Requirement
Test method
Group A
Visual and dimensional examination
Nonmagnetic 1/
Group B
Durometer
Compression
Group C
Infrared (IR) signature 2/
NOTES:
1/
When specified (see 6.2).
2/
One sample for IR testing shall be selected every 3 months from a batch of material used to
manufacture insert blocks.
4.4.1 Sampling for conformance inspection. As a minimum, the contractor shall randomly select a sample
quantity from each lot of completed penetrator frames, accessories, or insert material items in accordance with tables
IV and V and inspect them in accordance with 4.4. If one or more defects are found in any sample, the entire lot
shall be rejected. The contractor has the option of screening the lot 100 percent for the defective characteristic(s) or
providing a new lot which shall be inspected in accordance with sampling plan contained herein. The contractor
shall maintain for a period of three years after contract completion records of inspections, tests, and any resulting
rejections.
4.4.1.1 Group A inspection.
4.4.1.1.1 Frames. Visual and dimensional examination shall be performed on all frames offered for delivery.
The nonmagnetic inspection shall be in accordance with table IV.
4.4.1.1.2 All other parts. Samples of all other parts offered for inspection shall be selected from each lot in
accordance with table IV.
TABLE IV. Group A inspection sampling plan.
Lot size
Sample size
Accept
3 to 50
5
0
51 to 90
7
0
91 to 150
11
0
151 to 280
13
0
281 to 500
16
0
501 to 1200
19
0
1201 to 3200
23
0
3201 to 10,000
29
0
10,001 and over
35
0
10
