MIL-DTL-24749B(SH)
1.3 Part or Identifying Number (PIN). PINs to be used for bond straps acquired to this specification are created
as follows (see 6.2):
EXAMPLE: M24749-T-S-L-W-H
MS24749
T
S
L
W
H
Hole diameter (H) (optional only for Types II, III, and
IV bond straps, in nonstandard sizes, see 3.3).
Width (W) (optional only for Types II and III bond
straps, in nonstandard sizes, see 3.3).
Length (L) (optional only for nonstandard sizes,
see 3.3).
Standard size code (S), (N) size is nonstandard, see 3.3;
Bond strap type (T) (see 1.2.1).
I - Type I
II - Type II
III - Type III
IV - Type IV
Specification Number
EXAMPLE: MS24749-II-B, Type II bond strap, standard size B.
EXAMPLE: MS24749-III-23-5-0.375, Type III bond strap, 23 inches long, 5 inches wide, 3/8 inch (0.375 inch)
hole diameter.
1.3.1 Boss part or identifying number (PIN). PINs to be used for Type I bond strap bosses acquired to this
specification are created as follows (see 6.2):
Specification Number
Boss Type
EXAMPLE: MS24749-CR
CRES 316L
AL-SGC Aluminum/CRES 316L stud gun compatible
EXAMPLE: MS24749-AL-SGC
